Wrap-around labeling machine

Product

Product portfolio

CVC-300 U2

Suitable product

Suitable for labeling round cylindrical bottles, glass or plastic bottle materials

Specifications

The machine meets GMP standards for the pharmaceutical, cosmetics and food industries
Using decal label, not pure label, roll form
Controller by touch screen HMI
Machine has 100 sets of memory module which are easy for us to use
Using separator wheel or screw to detach the bottle before labeling
Motor servo for increased speed and accuracy
Automatic testing, put 1 bottle in the conveyor, start conveyor, machine is adjusted automatically and labeling
Main parts are made of stainless steel SUS#304
Can be integrated into an automated packaging line

Productivity	Labeling speed: max 200 pcs/min (depends on product size and label size)
Applicable size	- Label (LxW): 15 ~ 254 x 15 ~ 265 mm - Bottle (Dia.xH): 30 ~ 210 x 50 ~ 320 mm
Power source	110/220 V, 50/60 HZ, 1 PH
Power consumption	902 VA (110V: 8.2 A, 220V: 4.1 A)
Air pressure	6 bar
Machine dimensions (LxWxH)	2.000 x 1.070 x 1.425 mm (including conveyor)
Machine weight	200 kg
Noise level	<75 dB
